Product description

Dokio folding solar panel set.

Suitable for camping, travelling, outdoor activities, for example.

80W

• Material: monocrystalline silicon
• Maximum power (Pmax): 80W±3%
• Maximum power voltage (Vmp): 18.00V
• Maximum current (Imp): 4.44A
• Open circuit voltage (Voc): 22.50V
• Short circuit current (Isc): 4.69A
• Nominal operating cell temperature (NOCT): -45 to 80 ℃
• Maximum system voltage: DC1000V
• Folded size: 54 x 50 x 1.2 cm
• Expanded size: 100 x 54 x 0.6 cm
• Net weight: 2.4 kg
• Packing weight: 3.1 kg
• Packing size: 63 x 61 x 6 cm

100W

• Material: monocrystalline silicon
• Maximum power (Pmax): 100W±3%
• Maximum power voltage (Vmp): 18.00V
• Maximum current (Imp): 6.1A
• Open circuit voltage (Voc): 22.5V
• Short circuit current (Isc): 6.35A
• Nominal operating cell temperature (NOCT): -45 to 80 ℃
• Maximum system voltage: DC1000V
• Folded size: 70 x 50 x 1.2 cm
• Expanded size: 100 x 70 x 0.6 cm
• Net weight: 2.7 kg
• Packing weight: 3.6 kg
• Packing size: 75 x 58 x 7 cm

200W

• Material: monocrystalline silicon
• Maximum power (Pmax): 200W±3%
• Maximum power voltage (Vmp): 18.00V
• Maximum current (Imp): 11.12A
• Open circuit voltage (Voc): 22.50V
• Short circuit current (Isc): 11.36A
• Nominal operating cell temperature (NOCT): -45 to 80 ℃
• Maximum system voltage: DC1000V
• Folded size: 70 x 50 x 2.4 cm
• Expanded size: 216 x 72 x 0.6 cm
• Net weight: 5.3 kg
• Packing weight: 6.3 kg
• Packing size: 80 x 60 x 7 cm

300W

• Material: monocrystalline silicon
• Maximum power (Pmax): 300W±3%
• Maximum power voltage (Vmp): 18.00V
• Maximum current (Imp): 16.67A
• Open circuit voltage (Voc): 22.50V
• Short circuit current (Isc): 16.92A
• Nominal operating cell temperature (NOCT): -45 to 80 ℃
• Maximum system voltage: DC1000V
• Folded size: 100 x 50 x 2.4 cm
• Expanded size: 200 x 100 x 0.6 cm
• Net weight: 7.1 kg
• Packing weight: 8.2 kg
• Packing size: 108 x 57 x 7 cm

(The above data is based on a laboratory standard testing environment)

For on-site connection, use at least insulated copper wires of 12AWG.
